STOJEĆA ZRAČNA PUMPA

Upute za rukovanje

Uvod ..........................................................................................7

Namjenska uporaba ...............................................................7

Opseg isporuke ........................................................................7

Tehnički podaci .........................................................................7

Pažnja, sigurnosna napomena...............................................7

Puštanje pumpe u rad ..............................................................7

Adapter ...................................................................................... 8

Napomena za čišćenje & održavanje .................................8

Zbrinjavanje ..............................................................................8

Jamstvo .......................................................................................8

Uvjeti jamstva ............................................................................8

Trgovac ...................................................................................... 8

Adresa servisa ..........................................................................8

Uvod:

Srdačno čestitamo! Vašom kupnjom ste se odlučili za

visokovrijedan proizvod. Prije prvog puštanja u rad se

upoznajte sa proizvodom. U tu svrhu pažljivo pročitajte

sljedeće upute za rukovanje. Proizvod koristite isključivo na

opisan način i za navedena područja korištenja. Dobro

sačuvajte ove upute. U slučaju predaje proizvoda trećim

osobama eventualno priložite i ove upute.

Oznake u ovoj uputi za uporabu i montažu:

!

Ovaj znak vas upozorava na opasnost od ozljeda.

!

Dodatne informacije su označene na sljedeći način.

!

Namjenska uporaba:

Ova stajaća pumpa je prikladna za napumpavanje svih

uobičajenih vrsta guma za bicikl. Drugi načini uporabe

ili preinake proizvoda smatraju se nenamjenskim i mogu

dovesti do rizika nastanka ozljeda i oštećenja. Za štete,

koje proizlaze iz nenamjenske uporabe, osoba koja

proizvod stavlja u trgovinski promet ne preuzima nikakvu

odgovornost. Proizvod nije namijenjen uporabi u gospo

-

darske svrhe.

Opseg isporuke: (A1 / A2)

1 x Stojeća zračna pumpa

1 x Metalni adapter za lopte,

2 x Plastični adapter za dušeke, igračke za

napuhavanje itd.

1 x Upute za rukovanje

Tehnički podaci:

Tip: Stojeća zračna pumpa

IAN 272433

BROJ ARTIKLA: 26235

Monz-Nr. PO30000124

Nominalni tlak: 7 bara / 100 PSI

Maksimalni dopušteni tlak: 8 bara / 116 PSI

Zapremina rada: 370 ml / 370 cm³

Dužina tlačnog crijeva: 90 cm

Datum proizvodnje: 2016

Jamstvo: 3 godine

!

Pažnja, sigurnosna

napomena!

Možete napumpati sve gume za bicikl do navedenog

maksimalni dopušteni tlak pumpe (maks. 8 bara / 116

PSI) ili do maksimalnog tlaka zraka navedenog od strane

proizvođača gume. Ovaj navod se po pravilu nalazi na

bočnom dijelu gume. Navedene maksimalne vrijednosti ni

u jednom trenutku ne smiju biti prekoračene.

Upozorenje - U slučaju prekoračenja maksimalno

dopuštenih vrijednosti tlaka postoji opasnost od ozljede

uslijed eksplozije. Defektne ili oštećene pumpe za zrak

zbog opasnosti nastanka ozljede ne smiju biti korištene.

Defektne stajaće pumpe moraju biti zbrinute na prikladan

način. Popravke nisu moguće.

Oprez - Ukoliko dođe do oštećenja pumpe, crijeva,

adaptera ili do defektnih priključnih mjesta, postoji opa

-

snost od eksplozije. Zbog velike snage potrebne za rad

sa pumpom i time uvjetovanih rizika ovaj proizvod nije

prikladan za uporabu od strane djece i osoba sa tjelesnim

i/ili duševnim ograničenjima. Molimo obratite pažnju

na to, da se klip i cilindar pumpe u slučaju dugotrajnijeg

pumpanja zbog međusobnog trenja snažno zagrijavaju.

Zbog toga stajaću pumpu nakon pumpanja trebate zahva

-

tati isključivo preko rukohvata, kako biste izbjegli opekline.

Zbog opasnosti nastanka ozljeda nikada ne smijete koristiti

defektnu ili oštećenu stajaću pumpu.

Pažnja! Neki ventili za bicikl ne dopuštaju prikaz tlaka.

Za Vašu vlastitu sigurnost molimo Vas da tlak zraka kon

-

trolirate sa kalibriranim manometrom (npr. na benzinskoj

pumpi).

Puštanje pumpe u rad: (B1 / B4)

(B1) Stajaću pumpu postavite na stabilnu i ravnu podlogu.

(B2) Crijevo pumpe ne smije biti presavijeno.

(B3) Za vrijeme pumpanja stanite uvijek sa obje noge na

predviđenu površinu pumpe, tako da prevrtanje pumpe

bude onemogućeno.

(B4) Rukohvat pumpe aktivirajte ravnomjerno i ne prebrzo.

HR

Adapter: (C1)

(1) E.g. balls

(2) E.g. air mattresses

(3) E.g. inflatable boats

(4) To inflate inner tubes with schrader valves

e.g. mountain bikes, trolleys and trailers.

(5) To inflate inner tubes with blitz valves,

e.g. city/trekking bicycles

(6) For inflating inner tubes with a presta valve,

e.g. on racing bicycles and mountain bikes.

(7) Dual head (To lock in place, please fold

down the lever of the dual head.)

(Valves not included)

Inflating tyres with a schrader valve: (C2)

First remove the dust protection cap (1). Insert the

dual head with the large opening into the valve

(2). To lock in place, please fold down the lever of

the dual head (3).

Inflating tyres with a blitz valve: (C3)

First remove the dust protection cap (1). Insert the

dual head with the small opening into the valve

(2). To lock in place, please fold down the lever of

the dual head (3).

Inflating tyres with a presta valve: (C4)

First remove the dust protection cap (1). Detach

the valve nut (2a-2c). Insert the dual head with the

small opening into the valve (3). To lock in place,

please fold down the lever of the dual head (4).

Inflating air mattresses, inflatable toys, etc.: (C5)

First open the valve plug (1). Select the appropriate

plastic adapter and insert it into the large opening

of the dual head (2). To lock in place, please fold

down the lever of the dual head (3). Now insert the

plastic adapter into the object to be inflated (4).

Inflating balls: (C6)

Insert the metal adapter in the large opening of

the dual head (1). To lock in place, please fold

down the lever of the dual head (2). Now insert

the metal adapter into the ball (3).

!

Cleaning & care instructions:

- clean with a damp cloth

- do not immerse in water

- regularly inspect the floor pump’s screw joints

for secure attachment before use

- the floor pump is maintenance-free.

- Store the floor pump in a cool, dry place pro-

tected from UV light.

Disposal:

The packaging is made of 100% environmentally-

friendly materials which you can dispose of via

your local recycling points. Please obtain informa-

tion about the disposal options from your commu-

nity or municipal government.

Warranty:

Warranty of the Monz Handelsgesellschaft Interna-

tional MBH & CO. KG.

Dear customer, this device comes with a three-year

warranty, valid from the date of purchase. In case

of defects of this product, you will have legal rights

towards the seller of this product. These legal rights

shall not be limited by our warranty as set out below.

Warranty terms:

The warranty term starts on the date of purchase.

Please keep the original receipt in a safe place. This

document is required as proof of purchase.

If within a period of three years following the date

of purchase, this product displays material or manu-

facturing defects, we shall - at our discretion - repair

or replace the product free of charge. This warranty

assumes that within a period of three years the defec-

tive device and the proof of purchase (receipt) are

submitted and that a brief written description of the

defect, including when it occurred, is provided.

If the defect is covered by our warranty, you shall

receive a repaired or a new product. The repair or

exchange of the product does not commence a new

warranty term.

Distributor:

MONZ Handelsgesellschaft

International mbH & Co. KG

Metternichstr. 37, 54292 Trier / Germany

Service address:

MONZ SERVICE CENTER

c/o Teknihall Elektronik GmbH

Breitefeld 15, 64839 Münster / Germany

Hotline: 00800 / 68546854 (free of charge,

mobile networks may vary)

E-Mail: [email protected]

E-Mail: [email protected]

Dated: 01/2016
