REFRIGERATOR DIAGRAM

1.Freezing compartment

2.Temperature Controller

3.Shelves

4. Egg tray/door rack

5. Bottle rack

This diagram may vary slightly with the layout of the refrigerator you have

just purchased due to technical improvements.

PREPARATION

Unpacking

Remove all packaging materials.

Check attachments and materials

Please check that your appliance comes with all quoted accessories and that

all components are in good condition.

Ensure proper location of the refrigerator

Clean the refrigerator before fist use.

Ensure the appliance is located out of direct sunlight and away from other

heat producing appliances.

See also ventilation requirements (below).

Idle time

After the refrigerator has been sited and cleaned, let it stand for more than 30

minutes before connecting the power source.

Ventilation

* Level the appliance with a spirit level and a try square. The appliance has

adjustable feet.

* A minimum gap of 38mm must be maintained at the back of the appliance

for ventilation.

* Do not cover the air inlet at the front of the appliance and allow for 200cm²

air flow through plinth.

* Check the position of the power socket for usability and check the AC

voltage is compatible with the data shown on the rating plate which can be

found left inside wall of the appliance next to the salad crisper drawer(s). The

power supply must be suitably earthed.

Built-under Installation (Figure 2)

1. Check that the kitchen unit door is in the correct operating position.

2. Run the mains cable through the unit aperture so that it can be connected

to the power supply after installing the appliance. Remove the cover (6)

only if space is restricted.

3. Place the refrigerator into the kitchen unit. Fix the mountings (1) with

screws (2) onto the upper frame when two third of the refrigerator has

been pushed in. Then push the refrigerator in completely, ensuring that the

gib clamp of the mountings stuck on the horizontal frame of the kitchen

unit. Adjust the position of the refrigerator making a 6mm space between

inside wall of the kitchen unit and external sides of the refrigerators. Fix the

mountings to the horizontal frame of the kitchen unit with screws.

4. Insert the seal in the aperture (approx. 10mm) between the lower front

frame and bottom board of the kitchen. Fix lower mountings (3) to the

lower front frame with screws (2). Fix the lower mountings to the bottom

board of the kitchen unit with screws (2).

5. Properly insert seals in the apertures on the left, upper and right sides of

the refrigerator.

6. Fix the door to the holders (4) (each upper and lower position has one) with

screws (2). Press close the doors of the refrigerator and of the kitchen unit,

and then completely open the doors, and then place the connecting plate

(5)to the corresponding holder and fix it to the door of the kitchen unit

(space between the connecting plate and the edge of the kitchen unit "t"

equals to the thickness of the external board of the kitchen unit, about

20mm).Adjust the connecting element so that the handle side of the

kitchen unit door does not make contact with the unit body when closed.

(Approximately 1mm gap for large appliances), mount the second door

connecting element where appropriate.

7. Plug the open hole in the appliance door.

（Figure 2）

OPERATION

Starting the refrigerator

After connecting to the power supply, turn the temperature controller

clockwise from position 0 to any position between 1 and 7 to start the

refrigerator. The refrigerator compressor will stop when the temperature

controller is at position 0.

Adjusting the temperature:

The temperature inside the refrigerator is adjusted by turning the

temperature controller. Positions 1 to 7 represent different temperatures

from the lowest to the highest.

Position

Conditions

1-2

Summer or ambient

temperature between 25-

35 °C

3-4

Spring, autumn or ambient

temperature between 15-

25 °C

4-5

Winter, or ambient

temperature between 5-15

°C

6-7

Quick freeze

Caution: Some time will be required for the refrigerator to reach the set

level when temperature adjustments are made. The length of this period is

determined by difference in the existing and set temperatures, the ambient

temperature, the frequency with which the door is opened and closed and

the amount of food in storage.

Loading the refrigerator with food

When the refrigerator is switched on, do not load food until 1～2 hours have

passed. Usually, food for cold storage or deep freezing can be loaded when

the temperature inside the compartment reaches the set point.
