Using Turbo nozzle 5540

Precautions: Only use nozzle on carpets with a pile depth

under 15 mm. Do not use on animal skins or rugs with long

fringes. To avoid damaging your carpet, do not keep nozzle

stationary whilst brush is rotating. Do not pass nozzle over

mains cable and switch off nozzle immediately after use.

14

Attach turbo nozzle 5540 to tubes.

15

Note: Suction can also be regulated on turbo nozzle by

opening/closing air vent 5540.

Cleaning Turbo nozzle 5540

16

Disconnect from mains and remove entangled threads from

brush by snipping threads with scissors. Open cover to

remove any debris from inside nozzle.

Dust bag indicator and changing the dust bag

The dust bag should be changed when full.

5505/10/15/20/22/25/28 the dust bag indicator window will

turn red when filling and completely red when full.

5530/33/35/36/40 the dust bag indicator window will light up

when full. If the dust bag should accidentally get broken in the

cleaner, take cleaner to Electrolux Service Centre for cleaning.

To check the dust bag, the cleaner must be switched on,

with all attachments connected and off the floor.

The dust bag full indicator may signify that the bag is blocked

(occasionally caused by very fine dust) which will cause loss of

suction and may result in overheating. If this occurs change

the dust bag even if it is not full.

To change the dust bag:

A) Open the cleaner cover.

B) Pull the sliding tab to remove the dust bag.

C) Insert new dust bag by sliding the bag slots into the holder.

Close cover.

We recommend the dust bag is changed:

*

after using a carpet cleaning powder

*

if there is a bad smell from the cleaner, then you should also

change/clean the filter

Note: Use only Electrolux original dust bags (ref.E54A)

and filters:

Micro filter (ref. EF17)

Washable, reusable HEPA filter (ref. EF25a)

Dust bag safety device

To avoid damaging the cleaner, do not use it without a dust

bag. A safety device is fitted which prevents the cover closing

without a dust bag. Do not attempt to force cover shut.

Changing/Cleaning the filters

Never use the cleaner without the filters in place. The Motor

Protection filter should be changed twice a year for normal usage.

To change Motor Protection filter:

D) Open the cleaner cover.

E) Remove filter and covering strip.

F) Important: Insert new filter with original covering strip

securely in place. Close cover.

4

5

6

The Micro filter 5510/15/20/25/28 should be changed every

fifth dust bag.

To change Micro filter:

G) Open the filter cover.

H) Replace filter and close cover ensuring it is properly fastened.

The HEPA filter should be cleaned when the indicator light is

on

5530/33/35/36/40 or every fifth dust bag 5522.

To clean the HEPA filter:

I) Open the filter cover and remove filter unit.

J) Rinse the inside (dirty side) of the filter unit under warm tap

water only.

Do not use cleaning agents and avoid

touching the delicate filter surface.

Tap the filter frame

to remove excess water. Repeat cleaning procedure four

times and allow the filter to air dry. The original filtering

performance is now restored. Replace the unit back into the

cleaner and close cover ensuring it is properly fastened.

Troubleshooting

1. Power: If the electric power does not come on, disconnect

from mains and check plugs, cable and fuses where appropriate.

2. Blockage/dirty filters: The cleaner may switch itself off in

event of severe blockage or excessively dirty filters (on

5530/33/35/36/40 overheat indicator will flash). In such

cases, disconnect from mains and allow to cool for 30 minutes.

Clear blockage and/or replace filter(s) and restart.

The clearing of blocked hoses is not covered by the guarantee.

To avoid blockages and maintain suction efficiency, the floor

nozzles should be cleaned regularly using the hose handle.

Please see additional Electrolux information towards the back

of this booklet.

3. Water: If water is sucked into the cleaner the motor must be

changed at an Electrolux Service Centre.

If you have any comments on the cleaner or the Instruction for

Use Booklet please e-mail us on: floorcar[email protected]

2

For healthier homes

ANY PROBLEMS?

08706 055 055

CUSTOMER HELPLINE

for the UK

DON’T TAKE

Something missing?

Don’t understand the instructions?

We are only a telephone call away.

Need more help?

IT BACK TO THE SHOP

Local call cost Australia wide: 1300 369 333
