6

Walk Assist mode:

Pressing and holding the "–"button for 3 seconds activates Walk-Assist

Mode.

Change gears

Use the twist grip on the right side of the handlebars to operate the rear

derailleur. A gear engaged indicator, gear selected, is visible next to the

rotating handle.

To operate the derailleur with a twist grip, follow these steps: as follows:

a. Press the pedals forward.

b. Turn the ring (1) by hand clockwise to shift to a smaller sprocket, where

the pedaling eort will be greater.

c. Turn the gear shift ring by hand counterclockwise to move to a larger

gear, where the pedaling eort will be less.

1

Light operation

Lighting is one of the basic elements of bicycle user safety and it must be

installed. If you intend on riding in low visibility conditions, make sure that

the lighting works properly.

The bike is equipped with front and rear lights powered by AAA batteries.

To turn them on, press the button on the light.

Batteries are a product deemed to be dangerous, after use should be

discarded in a container assigned to it.

Battery & Charger maintenance

LITHIUM BATTERY

At the end of each use of the bicycle or if the battery is at, recharge the

battery.

After prolonged use the battery capacity will slowly decrease.

The average life of the battery depends on personal use and storage

conditions. Even with proper maintenance, rechargeable batteries are

not eternal. On average, a lithium battery remains active for about 500

charging cycles. It should be considered, however, that with each recharge

the "capacity" of the battery drops proportionally. Even partial recharges

(for example 1H recharge) are to be considered, for the purpose of the

number of possible cycles, as a complete recharge. Periodically fully

discharge the battery and recharge it.

If the bicycle is not used for a long period, keep the battery recharged at

least once every two months, leaving it to charge for about 4 hours. In this

case, do not pay attention to the battery charger lights.

When the battery is completely discharged it must be immediately

recharged. Do not leave the battery discharged unused but immediately

proceed with a recharge cycle. In this case, provide for a longer charging

cycle, of about 6 hours to allow complete activation of the battery.

It is recommended to use the bicycle once or twice a year until the battery

is completely discharged. Then fully charge it. This process has a benecial

eect on battery life.

Battery capacity on the display

When you turn on the bicycle engine and start pedalling, the battery icon

on the display indicates the instantaneous charge measured and not the

actual charge availability.

In case of uphill routes, when the engine is more stressed, the indicator

may show a reduced residual charge (the number of LEDs lit on the

display decreases). When the motor is stopped, in case of stop or advance

by inertia (for example downhill) the indicator may show a higher

available charge (in the absence of load on the engine the battery voltage

increases).

The best time, therefore, to achieve the amount of residual charge is when

reaching a constant speed and on a at and straight path after stabilizing

the work of the battery.

Battery charging

Recharge the battery without removing it from the frame.

At the end of each use of the bicycle, we do consider it worthwhile to

always recharge the battery. Keeping the battery charged at all times

extends its life.

It is compulsory to use the battery charger supplied and follow the

instructions on it. Do not use battery chargers not approved by SHARP.

They may damage the battery and limit its life. By using personal

accessories, not supplied with the bicycle, the legal guarantee will

automatically expire.

Before charging the battery, carefully read the following instructions and

follow them during the process.

• Use only the supplied battery charger.

• Keep both the battery charger and the battery away from children and

pets

• The charging operation must be carried out in a spacious, cool and dry

place; away from direct heat sources and humidity.

• If the charging operation takes place with the battery housed in the

bicycle, make sure that it is stable on the stand and turned o.

• It is normal for the battery charger to heat up during charging.

• Do not cover the battery charger.

• Keep the plugs always clean and dry.

• Do not get the battery charger wet.

• Do not use the battery charger and/or the battery if they are damaged.

• Always connect the battery charger to the battery rst and then to the

power socket.

• Do not carry out the charging process in direct sunlight.

• Do not use the battery charger for other purposes or for other devices.

• Voltage dips during charging cycles may damage the battery.

• Voltage drops during charging cycles could damage the battery.

Do not leave the battery connected to the charger, for more than 8 hours.

If the temperature of the battery rises too high, an unpleasant smell will be
