2

Table of contents

Inst ruction manual

Important safety information 3

Environmental protection 6

Saving energy 6

Environmentally-friendly disposal 6

Operating modes 6

Exhaust air mode 6

Air recirculation 6

Operating the appliance 7

Control panel 7

Remote control 7

Setting the fan 7

Intensive setting 7

Run-on function 8

Interval ventilation 8

Saturation display 8

Lighting 8

Safety shut-off 8

Cleaning and maintenance 9

Trouble shooting 12

Replacing the batteries in the remote control 13

Aftersales service 14

Accessory 14

: Additional information on products,

accessories, replacement parts and services can be

found at www.gaggenau.com and in the online shop

www.gaggenau.com/zz/store

3

m Important safety information

Read these instructions carefully. Only then will

you be able to operate your appliance safely and

correctly. Retain the instruction manual and

installation instructions for future use or for

subsequent owners.

The appliance can only be used safely if it is

correctly installed according to the safety

instructions. The installer is responsible for

ensuring that the appliance works perfectly at its

installation location.

This appliance is intended for domestic use and

the household environment only. The appliance

is not intended for use outside. Do not leave the

appliance unattended during operation. The

manufacturer is not liable for damage which is

caused by improper use or incorrect operation.

This appliance is intended for use up to a

maximum height of 2000 metres above sea level.

This appliance may be used by children over the

age of 8 years old and by persons with reduced

physical, sensory or mental capabilities or by

persons with a lack of experience or knowledge

if they are supervised or are instructed by a

person responsible for their safety how to use

the appliance safely and have understood the

associated hazards.

Children must not play with, on, or around the

appliance. Children must not clean the

appliance or carry out general maintenance

unless they are at least 15 years old and are

being supervised.

Keep children below the age of 8 years old at a

safe distance from the appliance and power

cable.

Check the appliance for damage after

unpacking it. Do not connect the appliance if it

has been damaged in transport.

This appliance is not intended for operation with

an external clock timer or a remote control.

Danger of suffocation!

Packaging material is dangerous to children.

Never allow children to play with packaging

material.

Danger of death!

Risk of poisoning from flue gases that are drawn

back in.

Always ensure an adequate air supply in the

room if the appliance is being operated in air

extraction mode at the same time as a non-room-

sealed heat-producing appliance.

Non-room-sealed heat-producing appliances

(e.g. gas-, oil-, wood- or coal-powered heaters,

continuous flow heaters or water heaters) draw

in combustion air from the room in which they

are installed and discharge the exhaust gases

into the open through an exhaust gas system

(e.g. a chimney).

While the ceiling ventilation is switched on, air is

extracted from the kitchen and adjacent rooms –

without sufficient supply air, this causes a

vacuum. Poisonous gases from the chimney or

the extraction shaft are drawn back into the

living space.

▯ Therefore, there must always be an

adequate air supply.

▯ A supply-/exhaust-air wall box alone will not

ensure compliance with the limit.

It is therefore only possible to safely operate the

appliance if the vacuum in the installation room

of the heat-producing appliance does not

exceed 4 Pa (0.04 mbar). This can be achieved

when the air needed for combustion is able to

enter through openings that cannot be sealed,

for example through doors, windows, supply-/

exhaust-air wall boxes or by other technical

means.

In any case, consult a chimney sweep. They are

able to assess the house's entire ventilation

setup and will suggest the ventilation measures

suitable for you.
